Recently, Dehong Friendship Hospital's integrated wiring project Jungong, Dehong Friendship Hospital is a private hospital invested by Lijiang Yushui Village Eco-Cultural Tourism Group. It is located in the west extension of the wide time road in Mangshi, Dehong Prefecture, with a land area of 74,000 square meters. 110 mu), with a total construction area of more than 160,000 square meters and a total investment of 820 million yuan. The first phase of the medical district officially broke ground on February 19, 2016. The construction period is expected to be 1 year and 6 months. The scale of the hospital is built according to the national three-level standard.
The Dehong Friendship Hospital project is a key project in Mangshi. The leaders of Dehong Friendship Hospital have attached great importance to the comprehensive wiring of the project. After several rounds of bidding, the Boloom Benlang integrated wiring system was finally confirmed. A total of 7,000 six types of unshielded information points are set up in this project, and another 150 Benlang luxury server cabinets are used.
In this project, Boloom's integrated wiring divides the hospital into two subnets, internal and external. The intranet data is used in the hospital's internal office computer network; the network voice is used for the internal telephone use of the hospital; the intranet AP is used in each ward for the doctor to use the handheld terminal during the rounds of the rounds, and wireless transmission is performed to check the medication situation of the patients in the ward. The external network is used to connect to the Internet, and is mainly located in the ward to provide convenience for patients and their families to access the Internet.
All sockets (including voice and data) of the intranet use six types of modules; horizontal cables for voice communication and data communication use CAT6 (six types) 4 pairs of UTP, in imaging workstations, CT rooms, X-ray angiography, fluoroscopy, radiation In the important functions such as the branch, fiber optic connection is used to ensure reliable transmission of data and anti-interference ability.
All outlets of the external network use Penang's unique card-free super five-type module, which facilitates the exchange of voice information points and data information points. The horizontal cable for voice communication and data communication uses CAT5E (Super Category 5) 4 pairs of UTP; it lays a foundation for good multimedia transmission of videophone in the future and increases the flexibility of the system.
The voice trunk cable uses Category 5 unshielded 25 pairs of large logarithmic twisted pairs. Data trunk cable uses two six-core multimode fibers (one for each of the inner and outer networks) in each wiring closet. Another four Category 6 UTP lines are used as spares for the backbone. The internal network of the horizontal data section of the floor data distribution frame adopts 24-port Cat6 24-port quick-connect type distribution frame; the external network adopts 24-port Cat5E 24-port quick-connect type distribution frame. The fiber-optic point horizontal cable in the internal network adopts four-core multi-mode indoor optical cable, and all the fiber points are from the working area, and are directly connected to the main wiring between the distribution lines to facilitate centralized management. The comprehensive ward building is connected to the original ward building and the outpatient building with a 12-core multimode outdoor fiber optic cable.
There are a large variety of pharmacy in the hospital, most of the pharmacy is still flammable, and the hospital is a place where the vulnerable groups are concentrated. The fire safety is a long way to go. We design in the hospital building intelligent system, all cables are low-smoke halogen-free (LSZH) outer sheath: LSZH Cat6 cable, LSZH Cat5e cable, LSZH four-core single-mode indoor cable, LSZH six-core single-mode indoor Cable.
